PISTON KIT 97-05 KDX220 69.00, WOSSNER 8092DC KAWASAKI

This Wossner piston kit with a 69.02mm bore (+0.02mm oversize, actual size 68.95mm) is designed for Kawasaki KDX220R models from 1998 to 2005. Forged in Germany, the piston delivers outstanding durability, efficient heat transfer, and long-term performance in two-stroke engine applications.

Features

• Forged piston construction for maximum strength and reliability

• Designed to enhance heat dissipation from combustion chamber to cylinder wall

• Elliptical profile ensures even load distribution and reduces stress to prevent piston collapse

• Manufactured in Germany to high-precision standards

Specifications

• Bore size: 69.02 mm

• Actual piston size: 68.95 mm

• Display (cm³): 216

• Stroke (mm): 58.00

• Clearance (mm): 0.06

• Compression ratio: 2-stroke (Wossner and OEM)

• Compression height (mm): 32.00

Vehicle Fitments

• 1998 Kawasaki KDX220

• 1999 Kawasaki KDX220

• 2000 Kawasaki KDX220

• 2001 Kawasaki KDX220

• 2002 Kawasaki KDX220

• 2003 Kawasaki KDX220

• 2004 Kawasaki KDX220

• 2005 Kawasaki KDX220

Included Components

• Piston: Wossner PN# 8092DC

• Lock: PN# CW16

• Pin: PN# WP027

• Ring Set: PN# RSB6900 x 2

• Rod: PN# P2033
