PISTON KIT 86-02 CR80 47.00 A, WOSSNER 8237DA HONDA MX 13110-GC4-505

Piston kit 47mm Bore 46.95 Wossner 8237DA (STD)

HONDA
CR80 1992 - 2002, (US BORE)

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W643.A.WO (oro2u.com)
Wossner Piston Honda CR80 47 mm Bore (PN# 8237DA)
Lock P/N CW14
Pin P/N WP058
Ring Set P/N RSB4700

Display (cm3) 80
Hub stroke (mm) 70.80
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 37.00
Theorectical weight (G)

Cross reference numbers ONLY.
13120-GBF-840, 13110-GC4-505, 643M04700,

1986 Honda CR 80 1987 Honda CR 80 1988 Honda CR 80 1989 Honda CR 80 1990 Honda CR 80 1991 Honda CR 80
