PISTON KIT 83-03 KX60 44.00, WOSSNER 8232D100 KAWASAKI MX

Wossner Piston Kit 8232D100 is a +1.00 oversize forged piston tailored for Kawasaki KX60 models from 1983 to 2003, featuring a 44.00mm bore. Manufactured in Germany, this piston is engineered for high strength and excellent thermal performance. Its elliptical design maintains an even bearing surface during heat expansion, reducing stress concentrations and helping to prevent piston failure.

Features

• Forged piston provides enhanced durability under demanding conditions

• Elliptical profile ensures consistent load distribution during thermal expansion

• Designed for optimal heat transfer to cylinder walls

• Precision manufactured in Germany

Specifications

• Bore: 44.00 mm

• Actual Piston Diameter: 43.95 mm

• Stroke: 41.60 mm

• Displacement: 60 cm³

• Clearance: 0.05 mm

• Compression Height: 23.50 mm

• Wossner Compression Ratio: 2-stroke

• OEM Compression Ratio: 2-stroke

Cross-Reference OEM Part Numbers

• Wossner Piston: 8232D100

• Lock: CW12

• Pin: WP091

• Ring Set: RSB4400

• Rod: P2001

• Internal Part No: 56-W648.P4.WO

Vehicle Fitments

• 1983 Kawasaki KX60

• 1984 Kawasaki KX60

• 1985 Kawasaki KX60

• 1986 Kawasaki KX60

• 1987 Kawasaki KX60

• 1988 Kawasaki KX60

• 1989 Kawasaki KX60

• 1990 Kawasaki KX60

• 1991 Kawasaki KX60

• 1992 Kawasaki KX60

• 1993 Kawasaki KX60

• 1994 Kawasaki KX60

• 1995 Kawasaki KX60

• 1996 Kawasaki KX60

• 1997 Kawasaki KX60
