PISTON KIT 41.00 HONDA NA50 NC50 PA50 NS50 Express 50, PISTON (STD) 13101-147-010 13103-187-023 RING SET (STD) 13010-GF8-306
SKU
56-W0074.4100.AAA
Retail Price
£29.74
£24.78
Trade Only: Please login or Click here to find a dealer
Out of stock
Pistons & Kits for off-road applications. Alt/OEM: 13010-GF8-306,13101-147-010,13103-187-023. SKU: 56-W0074.4100.AAA.
PRODUCT INFORMATION
| Weight | 0.084 kg |
|---|---|
| Product Type | Pistons & Kits |
| Product Group | Engine |
| Alternate SKU's | 13010-GF8-306, 13101-147-010, 13103-187-023 |
VEHICLE FITMENT
DESCRIPTION
Piston kit with a 41.00mm bore size designed as a direct OEM replacement for Honda NA50, NC50, PA50, NS50, and Express 50 models. Manufactured to precise tolerances for optimal fit and performance.
Features
- Meets or exceeds OEM quality standards
- Direct OEM replacement for easy installation
- Manufactured with tight tolerances for improved fit and durability
- Cost-effective alternative to high-cost pistons
- Reference image before ordering to ensure correct fit
- Made in China
Specifications
- Bore Size: 41.00mm
- Gudgeon Pin Outer Diameter: 10mm
- Crown Height: 20mm
- Piston Length: 48mm
- Ring Peg Position: 27mm
- Engine Type: 2-Stroke
Included Components
- Piston
- Piston Rings (x2)
- Wrist Pin (x2)
- Circlips (x1)
- Wrist Pin Roller Bearing (x1)
Cross-Reference OEM Part Numbers
- Piston (STD): 13101-147-010, 13103-187-023
- Ring Set (STD): 13010-GF8-306
Vehicle Fitments
- Honda NA50
- Honda NC50
- Honda PA50
- Honda NS50
- Honda Express 50
