PISTON KIT 1986 KX125 56.00, WOSSNER 8211DC KAWASAKI MX

This Wossner forged piston kit with a 56.02mm bore (55.96mm actual) is designed for the Kawasaki KX125 (1986). The piston is built for strength and thermal efficiency, with an elliptical design that helps distribute loads evenly and reduces the risk of localised stress and piston failure. Manufactured in Germany, this oversized (+0.02) piston kit is compatible with standard 2-stroke specifications and includes all necessary matching components.

Features

• Forged construction for high durability

• Optimised heat transfer to cylinder walls

• Elliptical shape for even thrust load distribution

• Manufactured in Germany

• Oversize (+0.02) piston for Kawasaki KX125 (1986)

Specifications

• Bore Size: 56.02mm (actual 55.96mm)

• Compression Height: 29.70mm

• Clearance: 0.06mm

• Stroke: 50.60mm

• Display Displacement: 211 cm³

• Compression Ratio: 2-stroke (Wossner and OEM)

• Dome Volume: Not specified

• Theoretical Weight: Not specified

Vehicle Fitments

• Kawasaki KX125 1986

Included Components

• Piston: Wossner 8211DC

• Lock: CW16

• Pin: WP036

• Ring Set: RSB5600

• Rod: P2037
