PISTON KIT 02-05 TC TE 250 76, WOSSNER 8576DB HUSQVARNA

Wossner 76.01mm (75.97mm) forged piston kit is designed for Husqvarna TE 250 and TC 610 models from 2002 to 2005. Engineered for strength and precision, this piston ensures efficient heat transfer to the cylinder walls, providing uniform expansion and reducing localized pressure. The elliptical design distributes thrust loads evenly, preventing piston collapse. Manufactured in Germany, it meets high-quality standards for reliable performance.

Features

• Wossner forged piston for superior strength and durability
• Optimized heat transfer for improved combustion efficiency
• Elliptical design for uniform bearing surface and reduced localized pressure
• Precision-engineered to prevent piston collapse
• Made in Germany

Specifications

• Bore Size: 76.01mm (75.97mm)
• Oversize: +0.01mm
• Displacement: 249cc
• Stroke: 55.00mm
• Clearance: 0.04mm
• Wossner Compression Ratio: 12.90:1
• OEM Compression Ratio: 12.50:1
• Dome Volume: -3.10cm³
• Compression Height: 23.50mm
• Lock Part Number: CW16
• Pin Part Number: WP059
• Ring Set Part Number: 760XAS
• Theoretical Weight: Not specified

Vehicle Fitments

• Husqvarna TE 250 (2002-2005)
• Husqvarna TC 610 (2002-2005)
