PISTON KIT 02-04 KX250 67.50, WOSSNER 8088D110 KAWASAKI MX

This Wossner forged piston kit with a 67.50mm bore (+1.10mm oversize) is specifically designed for Kawasaki KX250 models from 2002 to 2004. It features precision engineering for high performance, including a hard Teflon-coated skirt for optimal fit and adaptability to the cylinder bore. This oversized option is ideal for engines requiring significant bore refurbishment while maintaining strength and thermal efficiency under high-load conditions.

Features

• Forged construction delivers superior strength and durability

• Engineered for effective combustion heat transfer to cylinder walls

• Elliptical profile ensures even thrust load distribution and reduces piston collapse risk

• Hard Teflon skirt coating provides optimal fit and conformity to the cylinder bore

Specifications

• Bore: 67.50mm

• Actual Bore: 67.44mm

• Engine Displacement: 249 cm³

• Stroke: 72.00mm

• Clearance: 0.06mm

• Compression Ratio: 2-stroke (Wossner and OEM)

• Compression Height: 37.00mm

• Lock Part Number: CW18

• Pin Part Number: WP033

• Ring Set Part Number: RSB6750 x 2

• Rod Part Number: P2022

Vehicle Fitments

• 2002 Kawasaki KX250

• 2003 Kawasaki KX250

• 2004 Kawasaki KX250
