GASKET FULL SET TRX250 ATC250, EC/SX HONDA K&S 70-1044

The K&S Technologies 70-1044 complete top and bottom end gasket kit is a direct replacement engine gasket set for selected Honda TRX 250, ATC 250SX and ATC 250ES models. It is intended for a full engine rebuild and supplies the gaskets, O-rings and washers required for top and bottom end engine sealing work, using gasket materials sourced from Japan and the USA.

Features

• Direct replacement engine gasket kit
• Supports complete top and bottom end engine rebuilds
• Includes gaskets, O-rings and washers for whole-engine gasket replacement

Specifications

• Valve guide cylinder head O-ring size: 10 x 1.6
• Cylinder head O-ring size: 33.7 x 2.4
• Gasket materials sourced from Japan and the USA

Kit Contents

• Cylinder head gasket
• Cylinder base gasket
• 2 x Tappet cover gaskets
• Cam chain tensioner hole gasket
• Right crankcase cover gasket for ATC-250EX/SX 1985 only
• Right crankcase cover gasket except ATC-250ES/SX 1985
• Left crankcase cover gasket
• Crankcase gasket
• Starting gear cover gasket for 1985-1986 models
• Starting gear cover gasket for 1987 models
• 2 x Valve stem seals
• Exhaust pipe gasket
• 2 x Valve guide cylinder head O-rings
• Cylinder head O-ring for 1986-1987 models
• 2 x Cylinder head components

Cross-Reference OEM Part Numbers

• K&S Technologies 70-1044

Vehicle Fitments

• Honda TRX 250 FourTrax 250, 1985-1987
• Honda ATC 250SX, 1985-1986
• Honda ATC 250ES Big Red, 1985-1986
